Induction Motors - CPLS

Induction motors for variable frequency

Induction Motors

from 70 lb-ft to 2130 lb-ft (95 Nm to 2900 Nm)



The CPLS 3 phase AC variable speed induction motors are perfectly adapted to machinery requiring high dynamic performances in a very compact design.

The CPLS motor has been specifically designed to offer a reliable and adaptable asynchronous variable speed solution.

  • Advantages
    • Small dimensions thanks to its high specific output power (interchangeable with DC motors).
    • Possibility of working at high speed in test bench applications.
    • Economical: lower maintenance costs, competitive price of induction motor and drive assembly.
    • Wide speed range for work at constant power.
  • Main characteristics
    FRAME SIZE mm 112 to 250
    Number of poles 4
    Rated torque lb-ft/Nm 70 lb-ft to 2130 lb-ft (95 Nm to 2900 Nm)
    Speed rpm 0 to 10,000
    Voltage V 320 - 340 - 360 - 380 - 400 - 440 - 480
    Ingress protection IP 23
    Cooling IC06: forced ventilation unit
    Options Brake
  • Downloads
