Brushless DC Motors BLDC

Custom OEM 50-120mm BLDC Motors

Overview

U.S. MOTORS has a variety of 50mm-120mm custom BLDC motors, perfect for high-volume OEM applications specifically for medical equipment, however BLDC motors are often used for OEM applications involving:

Power tools
Household appliances
Sports and health equipment
Automotive industry.

Brushless DC (BLDC) Motors provide high-efficiency, robust construction, and energy saving advantages compared to other motor types. The examples above are just a few examples of many custom BLDC motors we can engineer to solve your unique challenges. For custom orders, please contact us so that we can learn more about your specific application.

Brushless DC Motors BLDC Series

50mm BLDC
Operating Modes: Variable Speed
Frame Size: External Rotor
Shaft Power: 30W ~ 100W
Voltage Range: DC 12/24/36V
Speed Range: 1000-3500 RPM
Max Motor Efficiency: 88%
PCBA: Sensor / Sensorless
76mm BLDC
Operating Modes: Variable Speed
Frame Size: Inner Rotor
Shaft Power: 50W ~ 150W
Voltage Range: DC 24/36/48 V | AC 110-120V, 220-230V
Speed Range:1000-3000 RPM
Max Motor Efficiency: 88%
PCBA: Sensor / Sensorless
95mm BLDC
Operating Modes: Variable Speed
Frame Size: Inner Rotor
Shaft Power: 100W ~ 400W
Voltage Range: DC 24/48 V | AC 110-120V, 220-230V
Speed Range: 1000-3600 RPM
Max Motor Efficiency: 90%
PCBA: Sensor / Sensorless

Available with or without controller
102mm BLDC
Operating Modes: Variable Speed
Frame Size: Inner Rotor
Shaft Power: 90W ~ 700W
Voltage Range: Phase I: AC 208 - 240V | Phase II: AC 360 ~ 400V
Speed Range: 300 - 4000 RPM
Max Motor Efficiency: 88%
PCBA:Sensor / Sensorless

Available with or without controller
120mm BLDC
Operating Modes: Variable Speed
Frame Size: Inner Rotor
Shaft Power: 250W ~ 1500W
Voltage Range: DC 48 V | AC 110-120V, 220-230V
Speed Range: 1000-3500 RPM
Max Motor Efficiency: 90%
PCBA: Sensor / Sensorless
